Large scale – floor standing mass production machine
adjustable ipad stand, tablet stand holders.
Specially designed for pre production and production lines
Coating width: 600mm to 1200mm
● Substrate size: 1200mm * 600mm
● Mold head: high-precision fluid simulation mold head
● Coating width: 600mm
● Dry film thickness: 200nm~2500nm
● Coating uniformity: ≤ 5%
● Double Y-axis transportation platform: air bearing+marble track+linear motor+servo system
● Longmen architecture: high-precision ball screw module+servo system+color laser coaxial displacement sensor
● Injection pump: high-precision liquid supply system
● Sample ejector pin: Alignment marble vacuum adsorption+lifting mechanism
● Pre coating module: automatic pre coating+automatic blade cleaning device
● Process pre drying device: precision air knife pre drying device
● PLC: Mitsubishi
● Motion control: Mitsubishi
● Operation: Customized professional software system, Mitsubishi touch screen
